Adaptation conditions:
Adaptation temperature: Minimum -5℃, Maximum 80℃;
Adaptation gas source: The exhaust pressure of compressed gas can be selected as 1.3MPa, 1.0MPa, or 0.8MPa (determined according to the density of the material and the mixing volume); The exhaust volume of compressed gas needs to be selected as the flow rate after drying and purification (engineers will provide based on the actual working conditions)
|
Model
|
Specification (Total Volume m)
|
Diameter (M)
|
Maximum particle size ratio
|
Maximum density ratio
|
Minimum mixing ratio
|
Mixing time
|
Mixed CV value
|
|
HDQH-400
|
0.5-2
|
~1.8
|
15:1
|
20:1
|
1:5000
|
5-12
|
≤2.5-5%
|
|
HDQH-600
|
2-30
|
~3
|
10:1
|
10:1
|
1:4000
|
10-15
|
≤2.5-5%
|
|
HDQH-800
|
30-50
|
~3.2
|
10:1
|
10:1
|
1:3000
|
15-25
|
≤2.5-5%
|
|
HDQH-1000
|
50-80
|
~3.4
|
5:1
|
5:1
|
1:2000
|
20-35
|
≤3-8%
|
|
HDQH-1200
|
80-120
|
~3.6
|
5:1
|
5:1
|
1:2000
|
25-45
|
≤5-10%
|
Note: The above parameters are subject to the design by the engineers.
Application industries: Chemicals, new energy, pesticides, pharmaceuticals, food, powder coatings, pigments, dyes, biology, ceramics, fertilizers, additives, plastics, casting, minerals, metallurgy, non-metallic materials, rubber, etc. for the homogenization of dry materials.
