QMX Series Bucket Elevators
1. They are particularly suitable for the transportation of various high-viscosity, high-humidity, high-flowability, semi-abrasive, flammable, explosive, toxic, irritating-smelling, corrosive powder and granular materials coming out of centrifuges.
2. The structure is unique. It can be combined in any direction within the vertical plane of the machine body, and multiple points of feeding and discharging can be controlled. It is a new type of conveying equipment that combines the advantages of bucket elevators and scraper machines.
3. The entire machine adopts a fully enclosed structure, with good air tightness. There is no dust leakage during the conveying process. It operates quietly with no abnormal noise.
4. The casing adopts a keel structure, which is compact and has good rigidity.
5. The conveying chain is a double-row chain and uses rollers and tracks, ensuring smooth operation and the rigidity of the chain.
QMX Conveyor Series Dimensions and Installation Sizes (mm)
|
Model
|
Discharge volume (m³)
|
Intermediate section dimensions (height × width)
|
Head shape dimensions
|
Line density (roots/25mm)
|
|
QMX150
|
6
|
340×351
|
1100×660×770
|
1100×660×770
|
|
QMX250
|
12
|
340×451
|
1100×660×870
|
1100×660×870
|
|
QMX350
|
24
|
340×551
|
1100×660×970
|
1100×660×970
|
|
QMX500
|
40
|
486×748
|
1500×800×1200
|
1200×800×1200
|
|
Horizontal length m
Model
Power kw
|
5-10
|
10-15
|
15-20
|
|
QMX150
|
4
|
5.5
|
7.5
|
|
QMX250
|
5.5
|
7.5
|
11
|
|
QMX350
|
5.5
|
7.5
|
11
|
|
QMX500
|
7.5
|
11
|
15
|
